- 4 Port Dual Monitor DVI KVM Switch mit USB 3.0 Hub
4 Images
Product description
USB 3.0 KVM Switch | TAA Compliant | 1920 x 1200 Digital Resolution | Stereo Audio & Mic
The TAA compliant Dual-Monitor DVI KVM Switch controls four multimedia computer systems from one dual-DVI monitor workstation.
Increase Productivity
The KVM switch supports four separate multimedia computer systems and the use of a dual DVI-D single-link monitor workstation, increasing productivity by enabling you to access more information at once.
Integrated USB 3.0 Hub
The 2-port hub that’s built into the USB 3.0 KVM switch shares two additional peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected while supporting high-performance peripherals such as flash drives and video capture devices.
Full Multimedia Support
With support for separate stereo audio and microphones, the KVM switch box connects everything you need directly to your systems, saving you money and desk space.
Easy to Operate
The front-panel push-buttons make it easy to switch between systems and activate the auto-scan feature. The hotkey functionality makes accessing each system quickly, while an optional buzzer sound confirms the switch.
StarTech.com offers a wide selection of high-quality KVM switches and KVM-related products to help you access your systems more efficiently without the expense and clutter of extra keyboards, mice, and monitors. This 4-port DVI USB KVM switch is backed by a 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- IMPROVE EFFICIENCY: 4 Port Dual Monitor DVI KVM Switch with hotkey and manual switching, to access 4 workstations or servers with USB and DVI video from a single keyboard, monitor, and mouse
- WORK SMARTER: Combines dual DVI displays and a high-speed 2-Port USB 3.0 hub to share USB devices between connected computers seamlessly; OS independent and works with video cards from NVIDIA and AMD
- TECH SPECS: 4 Port KVM
The TAA compliant Dual-Monitor DVI KVM Switch controls four multimedia computer systems from one dual-DVI monitor workstation.
Increase Productivity
The KVM switch supports four separate multimedia computer systems and the use of a dual DVI-D single-link monitor workstation, increasing productivity by enabling you to access more information at once.
Integrated USB 3.0 Hub
The 2-port hub that’s built into the USB 3.0 KVM switch shares two additional peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected while supporting high-performance peripherals such as flash drives and video capture devices.
Full Multimedia Support
With support for separate stereo audio and microphones, the KVM switch box connects everything you need directly to your systems, saving you money and desk space.
Easy to Operate
The front-panel push-buttons make it easy to switch between systems and activate the auto-scan feature. The hotkey functionality makes accessing each system quickly, while an optional buzzer sound confirms the switch.
StarTech.com offers a wide selection of high-quality KVM switches and KVM-related products to help you access your systems more efficiently without the expense and clutter of extra keyboards, mice, and monitors. This 4-port DVI USB KVM switch is backed by a 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- IMPROVE EFFICIENCY: 4 Port Dual Monitor DVI KVM Switch with hotkey and manual switching, to access 4 workstations or servers with USB and DVI video from a single keyboard, monitor, and mouse
- WORK SMARTER: Combines dual DVI displays and a high-speed 2-Port USB 3.0 hub to share USB devices between connected computers seamlessly; OS independent and works with video cards from NVIDIA and AMD
- TECH SPECS: 4 Port KVM
Technical specifications
Design
Product colour | Black |
Built-in display | N |
LED indicators | Y |
Bildschirm
On Screen Display (OSD) | N |
Anschlüsse und Schnittstellen
USB connector type | USB Type-B |
DC-in jack | Y |
DVI-I ports | 10 |
Number of microphone inputs | 5 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
Video port type | DVI-I |
Keyboard port type | USB |
Mouse port type | USB |
Console ports | 3.5mm headphone,3.5mm mic,DVI-I,USB A |
Number of computers controlled | 4 |
Console USB ports quantity | 4 |
Tastatur
Hot keys | Y |
USB hub | Y |
Maus
Certification | CE, FCC |
Leistungen
Housing material | Steel |
Daisy chain | Y |
Data transfer rate (max) | 5 Gbit/s |
Scan interval | 10,20,30,40,50,60 |
Nachhaltigkeit
Sustainability certificates | RoHS |
Stromversorgung
Energy consumption | 18 W |
Technische Details
AC input voltage | 100 - 240 |
Verpackungsdaten
AC adapter | Y |
Quick installation guide | Y |
Package weight | 300 g |
Package depth | 268 mm |
Package width | 160 mm |
Package height | 191.5 mm |
Leistung
Power source | AC |
Output current | 2 A |
Compatible power plug types | AU,EU,JP,UK,US |
Betriebsbedingungen
Operating relative humidity (H-H) | 0 - 90 |
Storage temperature (T-T) | -20 - 60 |
Operating temperature (T-T) | 0 - 40 |
Sonstige Funktionen
Headphone outputs | 5 |
External power adapter | Y |
Audio connections | Y |
Maximum resolution | 2048 x 1536 |
Output voltage | 9 |
Input current | 0.8 |
Maximum resolution | 1920 x 1200 |
Maximum analog resolution | 2048 x 1536 |
IP control | N |
Gewicht und Abmessungen
Weight | 1,300 g |
Height | 66 mm |
Width | 253 mm |
Depth | 100 mm |
Logistische Daten
Harmonized System (HS) code | 85176200 |
Master (outer) case height | 213 mm |
Master (outer) case width | 495 mm |
Master (outer) case length | 554 mm |
Products per master (outer) case | 6 ST |
