Cisco Unified Access is the convergence of the wired and wireless networks into one physical infrastructure with greater intelligence, simplicity, performance, and open interfaces. One network starts with Cisco Catalyst 3850 switches, which combine wired and wireless by supporting wireless tunnel termination and full wireless LAN controller functionality.
Best-in-Class Stackable Access Switch
The Cisco Catalyst 3850 Switch currently offers the industry's highest 480 Gbps stacking bandwidth to meet network demand, including gigabit desktop and 802.11ac wireless. The switch delivers advanced capabilities such as a high-performance 24/48 port GE switch, 480 G stacking, Power over Ethernet Plus, StackPower and Flexible NetFlow on all ports.
Converged Wired and Wireless Access
The Cisco Catalyst 3850 Switch brings Cisco IOS excellence to wireless by extending wired infrastructure features, resiliency, granular QoS, and scalability. It provides built-in wireless controller capabilities with 40 G wireless throughput, support for 50 access points and 2000 wireless clients per switch or stack, and support for 802.11ac.
Distributed Intelligent Services
The Cisco Catalyst 3850 Switch delivers common intelligent services across wired and wireless for security and policy, application visibility and control, network resiliency, smart operations, and more. The switch can enable multi-level QoS based on granular information such as SSID, client, radio, application, and fair share policies for wireless.
Foundation for Cisco Open Network Environment
The heart of Cisco Catalyst 3850 is the new ASIC with programmability for future features and intelligence with investment protection. The new ASIC provides a foundation for converged APIs across wired and wireless, software-defined networking (SDN) support, and Cisco One Platform Kit (OnePK).
Safety | UL 60950-1, CAN/CSA-C22.2, EN 60950-1, IEC 60950-1 |
LED indicators | Y |
Stackable | Y |
Gigabit Ethernet (copper) ports quantity | 24 |
Power over Ethernet (PoE) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Security algorithms | 802.1x RADIUS |
MAC address table | 32,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Link aggregation | Y |
Multicast support | Y |
VLAN support | Y |
Bandwidth | 480 Gbit/s |
Number of VLANs | 4,000 |
Routing entries | 24,000 |
Rate limiting | Y |
IP routing | Y |
Spanning tree protocol | Y |
Certification | RoHS |
Memory type | DRAM |
Mean time between failures (MTBF) | 269,450 std |
Management protocols | SNMP v1, SNMP v2c, SNMP v3 |
Switch type | Managed |
Access Control List (ACL) | Y |
IGMP snooping | Y |
AC input voltage | 100 - 240 |
User guide | Y |
Electromagnetic compatibility | 47CFR, AS/NZS CISPR22 2,CISPR22, EN55022, ICES003 |
Number of power supply units | 1 |
Power source | AC |
AC input frequency | 50 - 60 |
Power over Ethernet (PoE) | J |
Storage temperature (T-T) | -40 - 70 |
Operating temperature (T-T) | -5 - 45 |
Media types supported | 100BASE-FX, 1000BASE-SX, -LX/LH, -ZX, -BX10, DWDM/ |
Compatible products | Aironet 3600, 3500, 2600,1600, 1260, 1140, 1040 |
Networking standards | IEEE 802.11ac,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q, |
Technical features | PoE 435W |
Manual | Y |
Power LED | Y |
Power supply | 715 W |
Relative humidity | 10 - 95 |
Internal memory | 4,096 MB |
Flash memory | 2,048 MB |
Switching capacity | 88 Gbit/s |
Weight | 7,400 g |
Height | 445 mm |
Width | 445 mm |
Depth | 45 mm |
Harmonized System (HS) code | 85176990 |
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Power over Ethernet (PoE) J
Switch type Managed
Cisco Unified Access is the convergence of the wired and wireless networks into one physical infrastructure with greater intelligence, simplicity, performance, and open interfaces. One network starts with Cisco Catalyst 3850 switches, which combine wired and wireless by supporting wireless tunnel termination and full wireless LAN controller functionality.
Best-in-Class Stackable Access Switch
The Cisco Catalyst 3850 Switch currently offers the industry's highest 480 Gbps stacking bandwidth to meet network demand, including gigabit desktop and 802.11ac wireless. The switch delivers advanced capabilities such as a high-performance 24/48 port GE switch, 480 G stacking, Power over Ethernet Plus, StackPower and Flexible NetFlow on all ports.
Converged Wired and Wireless Access
The Cisco Catalyst 3850 Switch brings Cisco IOS excellence to wireless by extending wired infrastructure features, resiliency, granular QoS, and scalability. It provides built-in wireless controller capabilities with 40 G wireless throughput, support for 50 access points and 2000 wireless clients per switch or stack, and support for 802.11ac.
Distributed Intelligent Services
The Cisco Catalyst 3850 Switch delivers common intelligent services across wired and wireless for security and policy, application visibility and control, network resiliency, smart operations, and more. The switch can enable multi-level QoS based on granular information such as SSID, client, radio, application, and fair share policies for wireless.
Foundation for Cisco Open Network Environment
The heart of Cisco Catalyst 3850 is the new ASIC with programmability for future features and intelligence with investment protection. The new ASIC provides a foundation for converged APIs across wired and wireless, software-defined networking (SDN) support, and Cisco One Platform Kit (OnePK).
Safety | UL 60950-1, CAN/CSA-C22.2, EN 60950-1, IEC 60950-1 |
LED indicators | Y |
Stackable | Y |
Gigabit Ethernet (copper) ports quantity | 24 |
Power over Ethernet (PoE) ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Security algorithms | 802.1x RADIUS |
MAC address table | 32,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Link aggregation | Y |
Multicast support | Y |
VLAN support | Y |
Bandwidth | 480 Gbit/s |
Number of VLANs | 4,000 |
Routing entries | 24,000 |
Rate limiting | Y |
IP routing | Y |
Spanning tree protocol | Y |
Certification | RoHS |
Memory type | DRAM |
Mean time between failures (MTBF) | 269,450 std |
Management protocols | SNMP v1, SNMP v2c, SNMP v3 |
Switch type | Managed |
Access Control List (ACL) | Y |
IGMP snooping | Y |
AC input voltage | 100 - 240 |
User guide | Y |
Electromagnetic compatibility | 47CFR, AS/NZS CISPR22 2,CISPR22, EN55022, ICES003 |
Number of power supply units | 1 |
Power source | AC |
AC input frequency | 50 - 60 |
Power over Ethernet (PoE) | J |
Storage temperature (T-T) | -40 - 70 |
Operating temperature (T-T) | -5 - 45 |
Media types supported | 100BASE-FX, 1000BASE-SX, -LX/LH, -ZX, -BX10, DWDM/ |
Compatible products | Aironet 3600, 3500, 2600,1600, 1260, 1140, 1040 |
Networking standards | IEEE 802.11ac,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q, |
Technical features | PoE 435W |
Manual | Y |
Power LED | Y |
Power supply | 715 W |
Relative humidity | 10 - 95 |
Internal memory | 4,096 MB |
Flash memory | 2,048 MB |
Switching capacity | 88 Gbit/s |
Weight | 7,400 g |
Height | 445 mm |
Width | 445 mm |
Depth | 45 mm |
Harmonized System (HS) code | 85176990 |
