- Back-UPS Pro 1200 USV 230V 720Watt USB 6 Ausgangsstecker




2 Images




Product description
Energy-saving Back-UPS Pro 1200, 230 V
Powerful UPS with premium protection features for computers and electronic systems
- Automatically increases low voltage gradually and decreases high voltage to levels suitable for your equipment.
- Protection of data lines (Ethernet, coaxial and telephone lines) prevents damage to your systems caused by surges. It is very important to protect your systems against data line surges because they can be just as damaging as power line surges.
- Allows you to manage the UPS via the USB port.
- Important UPS status parameters at a glance: Multiple status displays with bar charts on load and battery status.
- Patent-pending operating mode in which unused electrical components are switched off when power conditions are good, allowing very high operating efficiency to be achieved without compromising safety.
- Power saving features automatically turn off peripheral devices when the master system, typically a PC, goes into standby mode or shuts down. Power to the peripherals will be restored immediately as soon as the master system is reactivated or turned on.
- Reserves capacity and backup time for connected devices that need to be switched to UPS battery operation in an emergency; Less important devices are only protected from surges
- Extends the service life and bridging time of batteries by correcting undervoltages without discharging the battery
Technical specifications
Design
Product colour | Black |
Batterie
Waveform | Sine |
Cold start | Yes |
Automatic battery test | Yes |
Typical backup time at half load | 15.7 min |
Battery capacity | 187 Vah |
Typical backup time at full load | 5.4 min |
Stromversorgung
Battery technology | Sealed Lead Acid (VRLA) |
Power
Battery recharge time | 8 std |
Maximum current | 10 A |
Surge protection | Yes |
Lieferumfang
Cables included | Phone (RJ-11), USB cable |
Verpackungsdaten
Bundled software | PowerChute Personal Edition |
Warranty card | Yes |
Software CD | Yes |
Package weight | 13800 g |
Package depth | 490 mm |
Package width | 235 mm |
Package height | 390 mm |
Sonstige Funktionen
Manual | Yes |
USB port | No |
Input frequency | 50/60 Hz |
Output power | 720 W |
Noise level | 45 dB |
Nominal input voltage | 230 V |
Nominal output voltage | 230 V |
Sustainability
Sustainability certificates | ENERGY STAR, Green Premium |
Operational conditions
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -15 - 45 °C |
Operating temperature (T-T) | 0 - 40 °C |
Operating altitude | 0 - 3000 m |
Storage relative humidity (H-H) | 0 - 95% |
Non-operating altitude | 0 - 15000 m |
Gewicht und Abmessungen
Weight | 13000 g |
Height | 301 mm |
Width | 112 mm |
Depth | 382 mm |
Ergonomics
LED indicators | Yes |
Features
Cable length | 1.83 m |
Audible alarm(s) | Yes |
Output frequency regulation | 50/60 Hz |
Surge protection features | Digital Subscriber Line (DSL), Fax, Modem, Network |
UPS topology | Line-Interactive |
Automatic Voltage Regulation (AVR) | Yes |
Efficiency | 98.8 % |
Surge energy rating | 441 J |
Output power capacity | 1.2 kVA |
Input operation voltage (max) | 300 V |
Input operation voltage (min) | 156 V |
Hold time (min) | 10 ms |
Hold time (max) | 12 ms |
Mouse
Certification | BSI 1363, CE, NEMKO, REACH |
Ports & interfaces
AC outlet types | Type F |
Number of type F outputs | 6 |
