- SMART-UPS SC 450VA 280W 1HE Rackmount seriell line-interactive inkl. Software 2 Jahre Herstellergarantie
2 Images
Product description
This product is part of the Smart-UPS range, an intelligent and efficient network power protection offer from entry-level to scalable runtime. This 450VA/280W line-interactive UPS provides pure sine wave power to support critical electronics during power disruptions. The 1U rackmount SC features network grade protection, live swappable batteries, and built-in data line protection. It comes with IEC 320 C14 input, 4x IEC 320 C13 outlets and 2x IEC jumpers. The UPS has a 2-year warranty. Its dimensions are 383mm (depth) x 44mm (height) x 432mm (width) and weighs 10.18kg. Ideal for networking equipment and POS devices. It conforms to C-Tick, CE, EAC, GOST, TISI, and VDE. Designed for small and medium businesses looking to protect networking equipment and point-of-sale (POS) devices from power disturbances and outages.
Technical specifications
Logistics data
| Products per pallet | 24 ST |
Weight & dimensions
| Weight | 10,180 g |
Power
| Battery recharge time | 5 std |
| Surge protection | Y |
Lieferumfang
| Cables included | RS-232 |
| Rack mount kit | Y |
Verpackungsdaten
| Software CD | Y |
| Package weight | 11,730 g |
| Package depth | 589 mm |
| Package width | 476 mm |
| Package height | 164 mm |
Sonstige Funktionen
| Manual | Y |
| Input frequency | 50/60 |
| Output power | 280 W |
| Noise level | 38 dB |
| Nominal output voltage | 230 |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 3000 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 15000 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Hot-swap battery | Y |
| Waveform | Sine |
| Automatic battery test | Y |
| Typical backup time at half load | 19.4 min |
| Battery capacity | 108 Vah |
| Typical backup time at full load | 5.9 min |
| Battery life (max) | 5 |
Ergonomics
| LED indicators | Battery replacement |
Features
| Height | 44 mm |
| Width | 432 mm |
| Depth | 383 mm |
| Audible alarm(s) | Y |
| Surge protection features | Digital Subscriber Line (DSL),Fax,Modem,Network |
| UPS topology | Line-Interactive |
| Audible alarm modes | Low battery alarm,Overload alarm |
| Automatic Voltage Regulation (AVR) | Y |
| Auto-restart | Y |
| Surge energy rating | 320 J |
| Output power capacity | 0.45 kVA |
| Input operation voltage (max) | 302 V |
| Input operation voltage (min) | 151 V |
| Hold time (min) | 4 ms |
| Hold time (max) | 8 ms |
Mouse
| Form factor | Rackmount/Tower |
| Certification | C-tick, CE, GOST, VDE, PEP, EOLI |
Ports & interfaces
| Serial ports quantity | 1 |
| Serial interface type | RS-232 |
| Power plug | C14 coupler |
| AC outlet types | C13 coupler |
| Number of output IEC jumpers | 2 |
| Serial interface | Y |
| AC outlets quantity | 4 AC out |
Design
| Product colour | Grey |
| Rack capacity | 1U |
Downloads
100050_document_DE_001
PDF Download
Reviews
ID: 100050
APC ID: SC450RMI1U
SMART-UPS SC 450VA 280W 1HE Rackmount seriell line-interactive inkl. Software 2 Jahre Herstellergarantie
Detailed product title
Detailed product title
APC Smart-UPS SC 450VA 230V - 1U Rackmount/Tower. UPS topology: Line-Interactive, Output power capacity: 0.45 kVA, Output power: 280 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 108 VAh, Typical backup time at full load: 5.9 min. Form factor: Rackmount/Tower, Product colour: Grey, Rack capacity: 1U. Compliance certificates: RoHS, Certification: C-tick, CE, GOST, VDE, PEP, EOLI
