- Smart-UPS RT 20kVA 230V Rackmount Fast Ethernet seriell 10 Ausgangsstecker 12U
3 Images
Product description
High-performance UPS systems with double-conversion online technology and scalable autonomy time
- The alphanumeric LC display shows system parameters and warnings
- Two mains inputs increase availability by connecting the UPS to two separate power sources
- Connectable to single or three phase power supply allows the UPS to be connected to a single or three phase power supply
- Rack/Tower combination device protects existing investments in the UPS when switching from a tower to a rack environment
- Scalable bridging time enables the bridging time to be quickly extended as capacity requirements increase
- An intelligent precision charging system optimizes the performance, service life and reliability of batteries
- Ensures uninterrupted power supply to protect systems during battery replacement
- Automatic restart of connected loads after UPS shutdown automatically starts up the connected devices when the mains voltage returns
- Charging the battery with temperature compensation extends the life of the battery by regulating the charging voltage according to the actual battery temperature
- Voltage conditioning protects connected devices from surges, voltage spikes, lightning strikes and other power supply disruptions
- Cold start support enables temporary battery operation if mains power fails
Technical specifications
Design
| Product colour | Black |
| Form factor | Rackmount/Tower |
| LED indicators | Y |
| Rack capacity | 12U |
Anschlüsse und Schnittstellen
| Serial interface type | RS-232 |
| Power plug | Terminal |
| AC outlet types | C19 coupler |
| Number of output IEC jumpers | 2 |
| Serial interface | Y |
| SmartSlot | Y |
| AC outlets quantity | 8 AC out |
Netzwerk
| Cabling technology | 10/100Base-T |
Maus
| Certification | EN/IEC 62040-2, EN/IEC62040-1-1, VDE, PEP, EOLI |
Merkmale
| Audible alarm(s) | Y |
| Output frequency regulation | 50/60 |
| Crest factor | 3:1 |
| Number of output phases | 1 |
| UPS topology | Double-conversion (Online) |
| Auto-restart | Y |
| Emergency Power Off (EPO) | Y |
| Efficiency | 95 % |
| Output power capacity | 15 kVA |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
Batterie
| Hot-swap battery | Y |
| Waveform | Sine |
| Cold start | Y |
| Automatic battery test | Y |
| Typical backup time at half load | 22.3 min |
| Battery capacity | 3,840 Vah |
| Typical backup time at full load | 8.3 min |
| Battery life (max) | 5 |
Nachhaltigkeit
| Sustainability certificates | RoHS |
Stromversorgung
| Battery technology | Sealed Lead Acid (VRLA) |
Lieferumfang
| Cables included | RS-232 |
| Rack mount kit | Y |
Verpackungsdaten
| Software CD | Y |
| Package weight | 314,090 g |
| Package depth | 1,003 mm |
| Package width | 610 mm |
| Package height | 990 mm |
Leistung
| Battery recharge time | 2.5 std |
| Maximum current | 90 A |
| Surge protection | Y |
Betriebsbedingungen
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 3000 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 15000 |
Sonstige Funktionen
| Manual | Y |
| Input frequency | 40 - 70 |
| Output power | 12,000 W |
| Noise level | 50 dB |
| Nominal input voltage | 230 |
| Nominal output voltage | 230 |
Gewicht und Abmessungen
| Weight | 247,730 g |
| Height | 533 mm |
| Width | 432 mm |
| Depth | 773 mm |
Logistische Daten
| Products per pallet | 1 ST |
ID: 102963
APC ID: SURT15KRMXLI
Smart-UPS RT 20kVA 230V Rackmount Fast Ethernet seriell 10 Ausgangsstecker 12U
Detailed product title
Detailed product title
APC Smart-UPS RT 15kVA 230V Rackmount, Fast Ethernet, seriell, 10 Ausgangsstecker, 12U, hörbarer Alarm, Not-Aus, LCD Anzeige, integr ierter statischer Bypass, interner Bypass, 2 Jahre Herstellergarantie
