- E3MUPS60KHS, Doppelwandler (Online), 60 kVA, 60000 W, Sine, 342 V, 477 V
1 Images
Product description
Easy to install, connect, use and service, the 60 kVA 3-phase UPS offers advanced product features, robust electrical specifications and compact design for easy business continuity. This UPS is EcoStruxure-enabled, so you can rest assured with cloud-based remote monitoring and management. It is ideal for small and medium-sized data centers and other mission-critical applications. It is delivered without batteries so you can easily customize your battery solution. Includes start-up service 5 x 8.
Technical specifications
Design
| Product colour | White |
| Form factor | Tower |
| LED indicators | Y |
Maus
| Certification | EN/IEC 62040-1, IEC 62040-2, IEC 62040-3, IEC 6204 |
Leistungen
| ECO mode | Y |
Merkmale
| Audible alarm(s) | Y |
| Crest factor | 3:1 |
| Number of output phases | 3 |
| UPS topology | Double-conversion (Online) |
| Number of input phases | 3 |
| Input power factor | 0.99 |
| Emergency Power Off (EPO) | Y |
| Output power capacity | 60 kVA |
| Output voltage Total Harmonic Distortion (THD) | 3 % |
| Input operation voltage (max) | 477 V |
| Input operation voltage (min) | 342 V |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 415 V |
| Output frequency | 50/60 |
Batterie
| Waveform | Sine |
| Cold start | Y |
Verpackungsdaten
| Package weight | 133,000 g |
| Package depth | 965 mm |
| Package width | 475 mm |
| Package height | 1,140 mm |
Leistung
| Maximum current | 104 A |
Betriebsbedingungen
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -25 - 55 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 1476.3 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 15000 |
Sonstige Funktionen
| International Protection (IP) code | IP20 |
| Input frequency | 40/70 |
| Output power | 60,000 W |
| Noise level | 65 dB |
Gewicht und Abmessungen
| Weight | 109,000 g |
| Height | 915 mm |
| Width | 360 mm |
| Depth | 850 mm |
Downloads
521195_document_EN_001
PDF Download
ID: 521195
APC ID: E3MUPS60KHS
E3MUPS60KHS, Doppelwandler (Online), 60 kVA, 60000 W, Sine, 342 V, 477 V
Detailed product title
Detailed product title
APC E3MUPS60KHS. USV-Topologie: Doppelwandler (Online), Ausgangskapazität: 60 kVA, Ausgangsleistung: 60000 W. Formfaktor: Tower, Pro duktfarbe: Weiß, Display-Typ: LCD. Breite: 360 mm, Tiefe: 850 mm, Höhe: 915 mm
