ID: 195626 Philips ID: 243B9/00

B Line 243B9 61cm (24") Display 1920x1080 Pixel 250 cd/m² 1000:1 4ms Schwarz

Detailed product title

Philips B Line 243B9 61cm (24") Display 1920x1080 Pixel 250 cd/m² 1000:1 4ms Schwarz

Response time 4

Display resolution 1920 x 1080

Contrast ratio (typical) 1000:1

Display brightness (typical) 250

Display diagonal 23.8

Product colour Black

Height adjustment Yes

Built-in speaker(s) Yes

immediately

Added to cart

immediately

Product description

The Philips B line monitor with USB-C docking replaces cable clutter. View Full HD image and re-charge your laptop, all at the same time with a single USB-C cable. SmartErgo base, Flicker-free and LowBlue mode make work easy-on-the eyes.

Technical specifications

Logistics data

Harmonized System (HS) code

85285210

Leistungen

TV tuner integrated	No
Component video sync	Separate sync,Sync-on-green (SOG)
Flicker-free technology	Yes
Low Blue Light technology	Yes
Mean time between failures (MTBF)	70,000

Design

Product colour	Black
Front bezel colour	Black
Heavy metals free	Hg (mercury),Pb (lead)
Feet colour	Black

Power

Energy efficiency scale	A to G
Energy efficiency class (SDR)	D
Power consumption (typical)	17.1
Power consumption (standby)	0.3
AC input voltage	100 - 240
AC input frequency	50 - 60
Power consumption (PowerSave)	12.8
Energy consumption (SDR) per 1000 hours	15

Lieferumfang

Cables included	AC,DisplayPort,HDMI,USB Type-C
Stand included	Yes

Verpackungsdaten

Package type	Box
Bundled software	SmartControl
Package weight	6,890
Package depth	198
Package width	600
Package height	475

Sonstige Funktionen

Manual	Yes
External power adapter	No
EasyRead mode	Yes
Digital horizontal frequency	30 - 85
Digital vertical frequency	48 - 75
Recyclable packaging material	100

Sustainability

Sustainability certificates	ENERGY STAR
Post-consumer recycled plastic	85
Compliance certificates	RoHS

Operational conditions

Operating relative humidity (H-H)	20 - 80
Storage temperature (T-T)	-20 - 60
Operating temperature (T-T)	0 - 40
Operating altitude	0 - 3658
Non-operating altitude	0 - 12192

Ergonomics

Cable lock slot type	Kensington
Cable lock slot	Yes
Plug and Play	Yes
VESA mounting	Yes
LED indicators	Operation,Stand-by
On Screen Display (OSD) languages	CHI (SIMPL),CHI (TR),CZE,DEU,DUT,ENG,ESP,FIN,FRE,GRE,HUN,ITA,JPN,KOR,POL,POR,RUS,SWE,TUR,UKR
Height adjustment	Yes
Pivot	Yes
On Screen Display (OSD)	Yes
Swivelling	Yes
On/off switch	Yes
Swivel angle range	-175 - 175
Tilt angle range	-5 - 30
Panel mounting interface	100 x 100
Height adjustment	150
Pivot angle	90 - 90

Multimedia

Number of speakers	2
Built-in camera	No
Built-in speaker(s)	Yes
RMS rated power	2

Computer system

Windows operating systems supported	Windows 10,Windows 7,Windows 8,Windows 8.1
Mac operating systems supported	Yes

Display

Backlight type	W-LED
Display technology	LED
Panel type	IPS
Display surface	Matt
Screen shape	Flat screen
Display number of colours	16.78 million colours
RGB colour space	sRGB
Touchscreen	No
Aspect ratio	16:9
Dynamic contrast ratio marketing name	SmartContrast
DDC/CI	Yes
Pixel pitch	0.275 x 0.275
Viewable size, horizontal	527
Viewable size, vertical	296.5
Response time	4
Display diagonal	23.8
Display resolution	1920 x 1080
Viewing angle, horizontal	178
Viewing angle, vertical	178
Pixel density	93
Maximum refresh rate	75
NTSC coverage (typical)	90
sRGB coverage (typical)	104
Display brightness (typical)	250

Mouse

Certification

CE Mark, FCC Class B, SEMKO, CU-EAC, TUV Ergo, TUV/GS, EPA, ICES-003, UKRAINIAN, CB

Video

Supported graphics resolutions	1920 x 1080 (HD 1080)
HD type	Full HD
3D	No
Supported video modes	1080p

Projector

Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	50000000:1
Horizontal scan range	30 - 85
Vertical scan range	48 - 75
Colour gamut	90

Ports & interfaces

DisplayPort version	1.2
USB Power Delivery revision	3.0
VGA (D-Sub) ports quantity	1
HDMI ports quantity	1
HDMI version	1.4
DisplayPorts quantity	1
DVI port	No
HDCP	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
HDMI	Yes
Headphone out	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of upstream ports	1
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
AC (power) in	Yes
PC Audio in	Yes
Built-in USB hub	Yes
USB Power Delivery up to	65

Weight & dimensions

Height (with stand)	522
Depth (with stand)	216
Width (with stand)	541
Weight (with stand)	5,190
Weight (without stand)	3,570
Width (without stand)	541
Height (without stand)	332
Depth (without stand)	63
