ColorEdge CS2731 68,6cm (27 Zoll) 2560x1440 Pixel 350cd/m² 1000:1 16ms Pivot

ID: 196775 EIZO ID: CS2731

ColorEdge CS2731 68,6cm (27 Zoll) 2560x1440 Pixel 350cd/m² 1000:1 16ms Pivot

Detailed product title

EIZO ColorEdge CS2731. Display diagonal: 68.6 cm (27"), Display resolution: 2560 x 1440 pixels, HD type: Quad HD, Display technology: LCD, Response time: 16 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub, USB hub version: 2.0 / 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black

Response time 16

Display resolution 2560 x 1440

Contrast ratio (typical) 1000:1

Display brightness (typical) 350

Display diagonal 27

Product colour Black

Height adjustment Yes

Built-in speaker(s) No

ship in 4-7 days

Added to cart

ship in 4-7 days

Product description

The CS2731 unites precision, colour fidelity and cutting-edge connectivity thanks to its USB-C port. This makes the monitor the central interface for the graphic workflow of sophisticated creatives with high standards. The wide gamut, 16-bit look-up-table and precise factory calibration of the CS2731 allows you to enjoy an unadulterated look at your image files in creative workflows requiring high colour accuracy. Convenient functionalities such as monitor signal transmission, rapid data transfer and the power supply feature for connected devices are enabled with just one USB-C port.

Technical specifications

Logistics data

Harmonized System (HS) code

85285210

Leistungen

TV tuner integrated	No
Flicker-free technology	Yes
Low Blue Light technology	Yes

Design

Product colour	Black
Feet colour	Black

Power

Energy efficiency scale	A to G
Energy efficiency class (SDR)	G
Power consumption (typical)	35.7
Power consumption (standby)	0.5
AC input voltage	100 - 240
AC input frequency	50/60
Power consumption (max)	159
Energy consumption (SDR) per 1000 hours	36

Lieferumfang

Cables included	AC,HDMI,USB Type-C to USB Type-C
Stand included	Yes

Technische Details

Market positioning

Photo editing

Verpackungsdaten

Quick start guide

Sonstige Funktionen

Separate H/V sync	Yes
Digital horizontal frequency	15 - 89
Digital vertical frequency	23 - 61
DCI-P3 coverage	95

Sustainability

Sustainability certificates	ENERGY STAR
Compliance certificates	RoHS

Operational conditions

Operating relative humidity (H-H)	20 - 80
Storage temperature (T-T)	-20 - 60
Operating temperature (T-T)	0 - 35
Storage relative humidity (H-H)	10 - 90

Ergonomics

Cable lock slot type	Kensington
Cable lock slot	Yes
VESA mounting	Yes
Height adjustment	Yes
Pivot	Yes
On Screen Display (OSD)	Yes
Swivelling	Yes
On/off switch	Yes
Swivel angle range	0 - 344
Tilt angle range	-5 - 35
Panel mounting interface	100 x 100
Height adjustment	155
Pivot angle	-90 - 90

Features

Colour depth

Multimedia

Built-in camera	No
Built-in speaker(s)	No

Display

Backlight type	W-LED
Display technology	LCD
Panel type	IPS
Screen shape	Flat screen
Display number of colours	1.073 billion colours
RGB colour space	sRGB
Anti-glare screen	Yes
Touchscreen	No
DDC/CI	Yes
Pixel pitch	0.233 x 0.233
Viewable size, horizontal	596.7
Viewable size, vertical	335.7
Response time	16
Display diagonal	27
Display resolution	2560 x 1440
Viewing angle, horizontal	178
Viewing angle, vertical	178
Pixel density	109
Maximum refresh rate	60
Adobe RGB coverage	99
sRGB coverage (typical)	100
Display brightness (typical)	350

Graphics

NVIDIA G-SYNC	No
AMD FreeSync	No

Mouse

Certification

CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241- 307), cTÜVus, TÜV/S, EAC, PSE, FCC-B, CAN ICES-3 (B), RCM, VCCI-B, CCC, RoHS, China RoHS, WEEE

Video

Supported graphics resolutions	2560 x 1440,1920 x 1200 (WUXGA)
HD type	Quad HD
Supported video modes	1080p,1080i,720p,576p,576i,480p,480i

Projector

Native aspect ratio	16:9
Contrast ratio (typical)	1000:1

Ports & interfaces

HDMI ports quantity	1
DisplayPorts quantity	1
DVI port	Yes
HDCP	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
HDMI	Yes
DVI-D ports quantity	1
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B,USB Type-C
Number of upstream ports	2
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
Number of USB Type-B upstream ports quantity	1
Built-in KVM switch	Yes
Built-in USB hub	Yes
USB Power Delivery up to	60

Weight & dimensions

Height (with stand)	404.1
Depth (with stand)	265
Width (with stand)	638
Weight (with stand)	10,100
Weight (without stand)	6,500
Width (without stand)	638
Height (without stand)	378.2
Depth (without stand)	75
