- FlexScan EV2410R 61,2cm (24,1") 1920x1200 Pixel 1300:1 350cd/m² 5ms Schwarz.
+3 Images
8 Images
Product description
The FlexScan EV2410R impresses as a flexible all-rounder and is ideal for the classic office workstation. Energy-saving, eyefriendly and ergonomic, it is an indispensable helper on any desk and enables efficient working. Equipped with an IPS panel, it has a horizontal and vertical viewing angle of 178° and a resolution of 1920 x 1200 pixels. The low-reflection surface, brightness and contrast ensure a detailed and excellent image reproduction. Auto EcoView automatically adjusts the brightness to the ambient light to avoid glare and protect the eyes. Four inputs for digital and analog signals, a USB hub and headphone and audio connections ensure versatile connectivity. Thanks to the thin housing edge, the monitor has a very compact appearance and is particularly suitable for multi-screen operation. In addition to the on-screen menu, the accompanying Screen InStyle software enables easy operation via computer or network.
Technical specifications
Bildschirm
| Supported graphics resolutions | 640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA) |
| Display technology | LCD |
| Panel type | IPS |
| Screen shape | Flat screen |
| Display number of colours | 16.7 million colours |
| Touchscreen | N |
| Pixel pitch | 0.27 x 0.27 |
| Horizontal scan range | 31 - 76 |
| Viewable size, horizontal | 518.4 mm |
| Vertical scan range | 59 - 61 |
| Viewable size, vertical | 324 mm |
| Display diagonal | 24.1 " |
| Display resolution | 1920 x 1200 |
| Viewing angle, horizontal | 178 deg |
| Viewing angle, vertical | 178 deg |
| Pixel density | 94 ppi |
| Display brightness (typical) | 350 cd/m² |
Leistungen
| Component video sync | Separate sync |
| Flicker-free technology | Y |
Power
| Energy efficiency class (SDR) | B |
| Energy efficiency class (HDR) | Not available |
| Power consumption (off) | 0 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 |
| Power consumption (max) | 54 W |
| Energy consumption (SDR) per 1000 hours | 8 kW.h |
Lieferumfang
| Cables included | DisplayPort,Power,USB Type-A to USB Type-B |
Technische Details
| Market positioning | Office |
| Response time | 5 ms |
Verpackungsdaten
| Quick start guide | Y |
Power supply
| Power consumption (typical) | 8 W |
Sonstige Funktionen
| Power management | Y |
| Manual | Y |
| Display diagonal (metric) | 61.1 cm |
Sustainability
| Sustainability certificates | ENERGY STAR,EPEAT Climate +,EPEAT Gold,TCO |
Gewicht und Abmessungen
| Height (with stand) | 358.4 mm |
| Depth (with stand) | 233 mm |
| Width (with stand) | 531 mm |
| Weight (with stand) | 6,000 g |
| Weight (without stand) | 3,900 g |
| Width (without stand) | 531 mm |
| Height (without stand) | 345.2 mm |
| Depth (without stand) | 57 mm |
Ergonomics
| Cable lock slot | Y |
| VESA mounting | Y |
| On Screen Display (OSD) languages | DEU,ENG,ESP,FRE,ITA |
| Height adjustment | Y |
| Pivot | Y |
| On Screen Display (OSD) | Y |
| Swivelling | Y |
| Swivel angle range | 0 - 344 |
| Tilt angle range | -5 - 35 |
| Panel mounting interface | 100 x 100 |
| Pivot angle | -90 - 90 |
Multimedia
| Number of speakers | 2 |
| Built-in camera | N |
| Built-in speaker(s) | Y |
| RMS rated power | 2 W |
Graphics
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
Mouse
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 10, TÜV/Low Blue Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC |
Video
| HD type | WUXGA |
Projector
| Native aspect ratio | 16:10 |
| Contrast ratio (typical) | 1300:1 |
Ports & interfaces
| VGA (D-Sub) ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| DisplayPorts quantity | 1 |
| Headphone outputs | 1 |
| HDCP | Y |
| HDMI | Y |
| Headphone out | Y |
| DVI-D ports quantity | 1 |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-B |
| USB Type-A downstream ports quantity | 4 |
| Number of USB Type-B upstream ports quantity | 1 |
| Built-in USB hub | Y |
Design
| Product colour | Black |
| Feet colour | Black |
ID: 704088
EIZO ID: EV2410R-BK
FlexScan EV2410R 61,2cm (24,1") 1920x1200 Pixel 1300:1 350cd/m² 5ms Schwarz.
Detailed product title
Detailed product title
EIZO FlexScan EV2410R. Display diagonal: 61.2 cm (24.1"), Display resolution: 1920 x 1200 pixels, HD type: WUXGA, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:10, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black
8 Images
Response time 5 ms
Display resolution 1920 x 1200
Contrast ratio (typical) 1300:1
Display brightness (typical) 350 cd/m²
Display diagonal 24.1 "
Product colour Black
Height adjustment Y
Built-in speaker(s) Y
