- FlexScan EV2740X-BK Computerbildschirm 68,6cm (27") 3840x2160 Pixel 4K Ultra HD 2000:1 350 cd/m² LCD Schwarz
+11 Images
16 Images
Product description
The EV2740X makes a clear statement for performance. 4K UHD resolution, USB-C docking and 94 W Power Delivery are convincing. Its 163 dpi display quality ensures crisp graphics and text. Docking convenience via its USB-C interface makes the FlexScan EV2740X the ideal display solution for professional office or CAD applications. Switching smoothly between office and home office is a breeze thanks to the USB-C port. Especially notebook and tablet users benefit from this. A single connection to the computer is sufficient for charging power, video signal, audio and USB data including network. The casing is available in black or white; even the cables are color-coordinated. The monitor is equipped with two HDMI ports as well as one DisplayPort and USB-C port each. With its two USB upstream ports, the EV2740X can be used as a keyboard/mouse switcher. For example, if both a home PC and a company computer are connected to the monitor in the home office, both computers can be operated with a single keyboard and mouse. When using its Picture-by-Picture function, it even displays two signal sources simultaneously.
Technical specifications
Design
| Product colour | Black |
| Anti-glare screen | Y |
Bildschirm
| Supported graphics resolutions | 720 x 400,1280 x 1024 (SXGA),3840 x 2160,800 x 600 (SVGA),2560 x 1440,1600 x 1200 (UXGA),1024 x 768 (XGA),1680 x 1050 (WSXGA+),640 x 480 (VGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA) |
| Backlight type | LED |
| Display technology | LCD |
| Panel type | IPS |
| Screen shape | Flat screen |
| Display number of colours | 16.7 million colours |
| RGB colour space | sRGB |
| Touchscreen | N |
| Pixel pitch | 0.155 x 0.155 |
| Viewable size, horizontal | 597 mm |
| Viewable size, vertical | 336 mm |
| Display diagonal | 27 " |
| Display resolution | 3840 x 2160 |
| Viewing angle, horizontal | 178 deg |
| Viewing angle, vertical | 178 deg |
| Pixel density | 163 ppi |
| Maximum refresh rate | 60 Hz |
| sRGB coverage (typical) | 100 % |
| Display brightness (typical) | 350 cd/m² |
Leistungen
| Flicker-free technology | Y |
| Low Blue Light technology | Y |
Power
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | D |
| Energy efficiency class (HDR) | Not available |
| Power consumption (standby) | 0.35 W |
| AC input voltage | 100 - 240 |
| AC input frequency | 50/60 |
| Power consumption (max) | 186 W |
| Energy consumption (SDR) per 1000 hours | 18 kW.h |
Lieferumfang
| Cables included | AC,USB Type-C to USB Type-C |
Technische Details
| Market positioning | Office |
| Response time | 5 ms |
Verpackungsdaten
| Quick start guide | Y |
Power supply
| Power consumption (typical) | 16 W |
Sonstige Funktionen
| Digital horizontal frequency | 31 - 135 |
| Digital vertical frequency | 29 - 61 |
| Display diagonal (metric) | 68.5 cm |
Sustainability
| Sustainability certificates | ENERGY STAR,EPEAT Climate +,EPEAT Gold,TCO |
| Sustainability compliance | Y |
Gewicht und Abmessungen
| Height (with stand) | 565 mm |
| Depth (with stand) | 242 mm |
| Width (with stand) | 612 mm |
| Weight (with stand) | 8,200 g |
| Weight (without stand) | 5,500 g |
| Width (without stand) | 612 mm |
| Height (without stand) | 359 mm |
| Depth (without stand) | 61 mm |
Ergonomics
| Cable lock slot type | Kensington |
| Cable lock slot | Y |
| VESA mounting | Y |
| On Screen Display (OSD) languages | DEU,ENG,ESP,FRE,ITA,SWE |
| Height adjustment | Y |
| Pivot | Y |
| On Screen Display (OSD) | Y |
| Swivelling | Y |
| Swivel angle range | -90 - 90 |
| Tilt angle range | -5 - 35 |
| Panel mounting interface | 100 x 100 |
| Height adjustment | 195 mm |
| Pivot angle | 0 - 90 |
Multimedia
| Built-in camera | N |
| Built-in speaker(s) | Y |
Graphics
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
Mouse
| Certification | CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 9, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC |
Video
| HD type | 4K Ultra HD |
Projector
| Native aspect ratio | 16:9 |
| Contrast ratio (typical) | 2000:1 |
Ports & interfaces
| DisplayPort version | 1.3 |
| HDMI ports quantity | 2 |
| Headphone connectivity | 3.5 mm |
| DisplayPorts quantity | 1 |
| Headphone outputs | 2 |
| HDCP | Y |
| USB Type-C DisplayPort Alternate Mode | Y |
| USB Power Delivery (USB PD) | Y |
| Ethernet LAN | Y |
| HDMI | Y |
| Headphone out | Y |
| USB upstream port type | USB Type-B,USB Type-C |
| Number of upstream ports | 2 |
| USB Type-A downstream ports quantity | 3 |
| USB Type-C downstream ports quantity | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| Number of USB Type-B upstream ports quantity | 1 |
| Built-in KVM switch | Y |
| Built-in USB hub | Y |
| USB Power Delivery up to | 94 W |
Downloads
481235_document_DE_001
PDF Download
481235_document_EN_001
PDF Download
