ID: 549762 Iiyama ID: XUB2497HSN-W2

ProLite XUB2497HSN-W2 60,5cm (23,8") 1920x1080 Pixel 1300:1 300cd/m² 1ms Pivot

Detailed product title

iiyama ProLite XUB2497HSN-W2 60,5cm (23,8") 1920x1080 Pixel 1300:1 300cd/m² 1ms Pivot

Response time 1

Display resolution 1920 x 1080

Display brightness (typical) 300

Display diagonal 23.8

Height adjustment Yes

Built-in speaker(s) Yes

ship in 4-7 days

Added to cart

ship in 4-7 days

Product description

Equipped with a USB-C dock connector, the XUB2497HSN allows you to simplify your workspace by using a single cable to both send signal from your notebook to your monitor and power and charge the notebook from the monitor. Additionally, if your monitor is connected to the Internet with a LAN cable, your notebook will automatically be connected to the network as well. Thanks to a DisplayPort output you can easily extend your desktop by creating a double-monitor set-up. Supplied with a 150mm height-adjustable stand featuring pivot and swivel functions, the XUB2497HSN allows you to easily adjust the screen position to your preferences. Available also without USB-C dock: XUB2497HSU-W2

Technical specifications

Technical details

User controls

picture adjust (brightness, contrast, Eco, ACR, OD, MBR, Adaptive Sync), colour settings (i-Style colour, blue light reducer, colour temp., user preset), OSD (OSD H. position, OSD V. position, OSD rotate, OSD time), language, recall, miscellanous 1 (sharp and soft, video mode adjust, opening logo, RGB range), miscellaneous 2 (USB BC, MST, USB, LED, display information, MAC address), input select, audio settings (volume, mute)

Other features

Packaging content

quick start guide, safety guide

Packaging data

Package depth	126
Package width	685
Package height	405

Weight & dimensions

Weight	5,300
Width	538.5
Depth	209.5

Packaging content

Quick start guide

Packaging data

Package type	Box
Package weight	7,400

Weight & dimensions

Height (with stand)	500
Depth (with stand)	209.5
Width (with stand)	538.5
Weight (with stand)	5,300
Width (without stand)	538.5
Height (without stand)	350
Depth (without stand)	209.5

Power

Power supply type	Internal
Energy efficiency scale	A to G
Energy efficiency class (SDR)	E
Energy efficiency class (HDR)	Not available
Power consumption (typical)	20
Power consumption (off)	0.3
Power consumption (standby)	0.5
AC input voltage	100 - 240
AC input frequency	50/60
Energy consumption (SDR) per 1000 hours	17.9

Ergonomics

VESA mounting	Yes
Height adjustment	Yes
Pivot	Yes
On Screen Display (OSD)	Yes
Swivelling	Yes
Swivel angle range	-60 - 60
Tilt angle range	5 - 23
Pivot angle	0 - 90

Ports & interfaces

HDMI ports quantity	1
HDMI version	1.4
HDCP	Yes
USB Power Delivery (USB PD)	Yes
HDMI	Yes
Headphone out	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of USB Type-C upstream ports quantity	1
Built-in USB hub	Yes
USB Power Delivery up to	65

Multimedia

Number of speakers	2
Built-in speaker(s)	Yes

Performance

AMD FreeSync	Yes
Flicker-free technology	Yes
VESA Adaptive Sync support	Yes
Low Blue Light technology	Yes

Display

Display technology	LED
HD type	Full HD
Display surface	Matt
Screen shape	Flat screen
Display number of colours	16.7 million colours
Touchscreen	No
Contrast ratio (dynamic)	80000000:1
DDC/CI	Yes
Pixel pitch	0.275 x 0.275
Horizontal scan range	30 - 110
Viewable size, horizontal	527
Viewable size, vertical	296.5
Response time	1
Display diagonal	23.8
Display resolution	1920 x 1080
Viewing angle, horizontal	178
Viewing angle, vertical	178
Maximum refresh rate	100
NTSC coverage (typical)	72
sRGB coverage (typical)	99
Display brightness (typical)	300
