- StarTech Triple-Head-Computer DVI/USB KVM Switch with Audio and USB 2.0 Hub 4 Port














+2 Images
7 Images














Product description
The SV431TDVIUA 4-Port Triple Monitor DVI USB KVM Switch allows 4 PCs (each with 3 DVI video outputs) to share monitors, 1 microphone and set of speakers, 1 keyboard and 1 mouse, as well as an additional USB 2.0 peripheral such as an external hard drive, thumb drive, printer, or webcam.
The Triple DVI KVM switch enables you to switch back and forth between 4 multi DVI PCs at the touch of a button, while maintaining professional-level video quality on all monitors at resolutions up to 1920x1200. The triple DVI KVM switch also features an integrated USB hub port which allows USB 2.0 peripherals to be shared between attached systems, eliminating duplicate peripheral costs and offering the convenience of sharing stored data between PCs.
The SV431TDVIUA 4-Port Triple Monitor DVI KVM Switch is backed by a StarTech.com 3-year warranty and free lifetime technical support.
PLEASE NOTE: While the DVI connector on this KVM is DVI-I, the KVM only supports single-link DVI-D (digital only) video sources. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to console connections.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
The StarTech.com Advantage
- By enabling control of four triple display computer systems using a single set of peripherals, the switch helps saves cost and work space
- With support for high definition resolutions (1920x1200) on each of the 3 connected monitors, the triple head KVM switch offers maximum screen real estate for optimized productivity
- Integrated USB 2.0 hub and mic/audio ports enable you to have full multimedia control of two computers, while sharing USB peripherals
The Triple DVI KVM switch enables you to switch back and forth between 4 multi DVI PCs at the touch of a button, while maintaining professional-level video quality on all monitors at resolutions up to 1920x1200. The triple DVI KVM switch also features an integrated USB hub port which allows USB 2.0 peripherals to be shared between attached systems, eliminating duplicate peripheral costs and offering the convenience of sharing stored data between PCs.
The SV431TDVIUA 4-Port Triple Monitor DVI KVM Switch is backed by a StarTech.com 3-year warranty and free lifetime technical support.
PLEASE NOTE: While the DVI connector on this KVM is DVI-I, the KVM only supports single-link DVI-D (digital only) video sources. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to console connections.
Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
The StarTech.com Advantage
- By enabling control of four triple display computer systems using a single set of peripherals, the switch helps saves cost and work space
- With support for high definition resolutions (1920x1200) on each of the 3 connected monitors, the triple head KVM switch offers maximum screen real estate for optimized productivity
- Integrated USB 2.0 hub and mic/audio ports enable you to have full multimedia control of two computers, while sharing USB peripherals
Technical specifications
Design
Product colour | Black |
Built-in display | N |
Logistics data
Harmonized System (HS) code | 85176200 |
Leistungen
Housing material | Steel |
Daisy chain | N |
Number of users | 1 |
Scan interval | 3,8,15,30 |
Power
AC input voltage | 110-240 |
Output current | 1.5 A |
Compatible power plug types | EU,UK,US |
Verpackungsdaten
AC adapter included | Y |
Package weight | 2,200 g |
Package depth | 297 mm |
Package width | 272 mm |
Package height | 108 mm |
Rubber feet | Y |
Sonstige Funktionen
Power plug type | Type M |
Manual | Y |
Rack mounting | Y |
External power adapter | Y |
Audio connections | Y |
Maximum resolution | 1920 x 1200 |
Output voltage | 12 |
Input current | 0.8 |
Maximum digital resolution | 1920 x 1200 |
Audio support | Y |
IP control | N |
Sustainability
Sustainability certificates | RoHS |
Operational conditions
Operating relative humidity (H-H) | 0 - 80 |
Storage temperature (T-T) | -10 - 60 |
Operating temperature (T-T) | 0 - 40 |
Gewicht und Abmessungen
Weight | 1,496 g |
Height | 81 mm |
Width | 219 mm |
Depth | 137 mm |
Ergonomics
LED indicators | Y |
Mouse
Certification | CE, FCC, UL |
Keyboard
Hot keys | Y |
Ports & interfaces
Headphone outputs | 4 |
HDCP | Y |
DC-in jack | Y |
Number of microphone inputs | 4 |
Video port type | DVI-I |
Keyboard port type | USB |
Mouse port type | USB |
Console ports | 3.5mm headphone,3.5mm mic,USB A |
Number of computers controlled | 4 |
Console USB ports quantity | 4 |
Downloads
124210_document_DE_001
PDF Download
124210_document_DE_002
PDF Download
124210_document_EN_001
PDF Download
ID: 124210
