ID: 140619 HP Enterprise ID: JH262A

HP FlexFabric 12904E Switch Chassis Switch L3 Managed an Rack montierbar

Detailed product title

HP FlexFabric 12904E Switch Chassis Switch L3 Managed an Rack montierbar

please ask for availability

Added to cart

please ask for availability

Product description

The HPE FlexFabric 12900E Switch Series offers a non-blocking, lossless Clos architecture with VOQs and large buffers with the flexibility and scalability required for future expansion.
The HPE FlexFabric 12900E Switch Series' high-performance, fully distributed architecture delivers up to 184 Tbps switching capacity and 92.16 Bpps throughput with non-blocking wirespeed performance.
The HPE FlexFabric 12900E Switch Series lets you create Layer 2 fabrics that are flexible, resilient, and scalable with VxLAN, TRILL, and/or Hewlett Packard Enterprise IRF.
Intelligent Resilient Fabric (IRF) can be used to create virtual, resilient switching fabrics in which two or more HPE FlexFabric 12900E switches function as a single Layer 2 switch and Layer 3 router, connected via standard LACP for automatic load balancing and connected to provide high availability.

Technical specifications

Other features

Flash memory

1,024 MB

Other features

Weight (imperial)

79.37 lb

Other features

Weight

36,000 g

Performance

Internal memory	8,000 MB
Processor frequency	1,200 MHz

Weight & dimensions

Dimensions (WxDxH)

439.9 x 857 x 263.9

Power

AC input voltage	100 - 240
Power consumption (max)	2,400 W

Weight & dimensions

Design

Rack mounting

Ports & interfaces

I/O ports

(4) I/O module slots; Supports 192 1/10/40/100 GbE ports or 96 400 GbE ports or a combination

Operational conditions

Operating relative humidity (H-H)

5 - 95

Computer system

Built-in processor

Features

Memory type

DDR3-SDRAM

Features

Output voltage

48 - 60

Other features

Performance management	IMC - Intelligent Management Center; Command-line interface; Out-of-band management (serial RS-232C); SNMP manager; Telnet; Terminal interface (serial RS-232C); Modem interface; IEEE 802.3 Ethernet MIB; Ethernet interface MIB
Latency	< 5 microseconds (64-byte packets)
Memory and processor	Quad Core MIPS64 @ 1.2 GHz, 1 GB flash, 8 GB DDR3 SDRAM Quad Core Intel X86 @ 2.2GHz , 8 GB flash, 16 GB DDR3 SDRAM (Type X and H2 modules)

Power
