Cisco Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
The Meraki MS is managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files or even direct physical access to the switch.
Meraki’s centralized management gives administrators deep visibility into the network and how it’s used. See which switches are near capacity across hundreds of sites. Find all configuration changes made by a certain person with instant search.
Product colour | Silver |
Form factor | 1U |
Stackable | Y |
Console port | RJ-45 |
SFP module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
Security algorithms | 802.1x RADIUS,SNMP |
Web-based management | Y |
MAC address table | 16,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Auto MDI/MDI-X | Y |
Link aggregation | Y |
Multicast support | Y |
VLAN support | Y |
Number of VLANs | 4,094 |
Jumbo frames | 9,578 |
Port mirroring | Y |
Auto-negotiation | Y |
Broadcast storm control | Y |
IP routing | Y |
Spanning tree protocol | Y |
10G support | N |
Certification | CSA-US, FCC, IC, CE, RCM, RoHS |
Mean time between failures (MTBF) | 590,165 std |
Physical stacking (units) | 8 |
Firmware upgradeable | Y |
Switch type | Managed |
Switch layer | L3 |
Password protection | Y |
Access Control List (ACL) | Y |
System event log | Y |
IGMP snooping | Y |
DHCP features | DHCP snooping,DHCP relay |
Root protection | Y |
BPDU filtering/protection | Y |
Energy consumption | 15 W |
AC input voltage | 100 - 240 |
Number of trunks | 8 |
Throughput | 41.67 Mpps |
Screws included | Y |
AC input frequency | 47/63 |
Power consumption (max) | 24 W |
Power over Ethernet (PoE) | N |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | 0 - 40 |
Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,I |
Rack mounting | Y |
Flow control support | Y |
Switching capacity | 128 Gbit/s |
Weight | 2,730 g |
Height | 43.8 mm |
Width | 484.6 mm |
Depth | 250 mm |
Harmonized System (HS) code | 85176990 |
