- Symmetra LX 8kVA N+1, 8 kVA, 5600 W, 155 V, 480 V, 50/60 Hz, 220 V
1 Images
Product description
APC Symmetra, 5600 Watts / 8000 VA, Input 230V, 400V 3PH / Output 230V , Interface Port DB-9 RS-232, Smart-Slot , Extended runtime model
Includes: CD with software, Documentation CD, Installation guide, User Manual, Web/SNMP Management Card
Standard Lead Time: Usually in Stock
Includes: CD with software, Documentation CD, Installation guide, User Manual, Web/SNMP Management Card
Standard Lead Time: Usually in Stock
Technical specifications
Design
| Form factor | Tower |
| Safety | C-tick, CE, EN 50091-1,EN 50091-2, EN 55022Class |
Anschlüsse und Schnittstellen
| RS-232 ports | 1 |
| AC outlets quantity | 1 AC out |
Stromversorgung
| Battery technology | Sealed Lead Acid (VRLA) |
Verpackungsdaten
| Package weight | 229,560 g |
Leistung
| Battery type | SYBT5 |
| Battery recharge time | 3 std |
Betriebsbedingungen
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 45 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 3000 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 4500 |
Sonstige Funktionen
| Dimensions (WxDxH) | 483 x 726 x 671 |
| Package dimensions (WxDxH) | 599 x 997 x 914 |
| Input frequency | 50/60 |
| Output power | 5,600 W |
| Noise level | 62 dB |
| Nominal input voltage | 230-400 |
| Nominal output voltage | 230 |
Gewicht und Abmessungen
| Weight | 201,820 g |
| Height | 671 mm |
| Width | 483 mm |
| Depth | 726 mm |
Features
| Crest factor | 5:1 |
| Emergency Power Off (EPO) | Y |
| Efficiency | 90 % |
| Input current Total Harmonic Distortion (THD) | 7 % |
| Output power capacity | 8 kVA |
| Output voltage Total Harmonic Distortion (THD) | 5 % |
| Input operation voltage (max) | 480 V |
| Input operation voltage (min) | 155 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
ID: 521367
APC ID: SYAF8KI
Symmetra LX 8kVA N+1, 8 kVA, 5600 W, 155 V, 480 V, 50/60 Hz, 220 V
Detailed product title
Detailed product title
APC Symmetra LX 8kVA N+1. Ausgangskapazität: 8 kVA, Ausgangsleistung: 5600 W, Eingangs-Betriebsspannung (min): 155 V. Anzahl der AC- Ausgänge: 1 AC-Ausgänge. Akku-/Batterietechnologie: Plombierte Bleisäure (VRLA), Akkuladezeit: 3 h. Formfaktor: Tower, Sicherheit: -tick, CE, EN 50091-1, EN 50091-2, EN 55022 Class A, EN 55024, EN 60950, GOST, IEC 60950, VDE. Breite: 483 mm, Tiefe: 726 mm, Höhe: 671 mm
