Product description
Are you looking to run edge AI workloads like Computer Vision that need GPU accelerators or distributed data solutions that require expandable storage? The HPE ProLiant DL320 Gen11 is a 1U 1P server with a unique compact design and workload-driven modular design that is purpose-built for edge computing delivering exceptional performance at 1P economics and an excellent choice for both virtualized and containerized workloads. Powered by 4th and 5th Gen Intel Xeon Scalable Processors with up to 60 cores, 270W, increased memory capability (up to 2 TB 5600 MT/s), and high-speed PCIe Gen5 supporting up to four single-wide GPUs (or two double-wide), the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution. The HPE ProLiant Gen11 servers are engineered to optimize IT at the edge with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.
What is new supporting point:
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Support for up to 4 Single Wide or 2 Double Wide GPUs in the front cage with the GPU CTO server.
What is new supporting point:
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.
Support for up to 4 Single Wide or 2 Double Wide GPUs in the front cage with the GPU CTO server.
Technical specifications
Speichermedium
Optical drive type | N |
SSD interface | SATA |
HDD interface | SATA |
RAID support | Y |
Number of HDDs supported | 8 |
Supported SSD sizes | 2.5" |
Number of SSDs supported | 8 |
Total storage capacity | 0 GB |
Supported HDD sizes | 2.5 |
Leistungen
Trusted Platform Module (TPM) version | 2.0 |
Trusted Platform Module (TPM) | Y |
Hot-Plug support | Y |
Thin Client
Motherboard chipset | Intel C741 |
Power
Number of redundant power supplies supported | 2 |
Number of redundant power supplies installed | 1 |
Redundant power supply (RPS) support | Y |
Festplatte
RAID levels | 0,1,5,10 |
Sonstige Funktionen
Rack mounting | Y |
Power supply | 500 W |
Maximum storage capacity | 20 TB |
Maximum graphics card memory | 16 MB |
Sustainability
Sustainability certificates | ENERGY STAR |
Operational conditions
Operating relative humidity (H-H) | 8 - 90 |
Storage temperature (T-T) | -30 - 60 |
Operating temperature (T-T) | 10 - 35 |
Operating altitude | 0 - 3050 |
Storage relative humidity (H-H) | 5 - 95 |
Non-operating altitude | 0 - 9144 |
Features
Compatible operating systems | Microsoft Windows Server VMware ESXi Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Canonical Ubuntu Oracle Linux and Oracle VM Citrix Community Enterprise Linux (CentOS, Alma Linux, Rocky Linux) |
Height | 42.8 mm |
Width | 434.6 mm |
Depth | 605.1 mm |
Computer system
Operating system installed | N |
Graphics
On-board graphics card | Y |
Memory
Internal memory type | DDR5-SDRAM |
Memory slots | 16x DIMM |
ECC | Y |
Maximum internal memory | 2,048 GB |
Memory clock speed | 4,800 MHz |
Internal memory | 16 GB |
Memory layout (slots x size) | 1 x 16 |
Network
LAN controller | Broadcom BCM5719 |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN | Y |
Processor
Processor manufacturer | Intel |
Processor family | Intel Xeon Bronze |
Processor model | 3408U |
Processor cores | 8 |
Maximum number of SMP processors | 2 |
Number of processors installed | 1 |
Processor cache | 22.5 MB |
Processor boost frequency | 1.9 GHz |
Processor frequency | 1.8 GHz |
Ports & interfaces
Ethernet LAN (RJ-45) ports | 2 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
Management features
Remote administration | iLO 6 ASIC |
Design
Chassis type | Rack (1U) |
Downloads
550343_document_DE_001
PDF Download
550343_document_EN_001
PDF Download
ID: 550343
HP Enterprise ID: P57686-B21
DL320 GEN11 3408U 1P 16G -STOCK
Detailed product title
Detailed product title
HPE ProLiant DL320 Gen11 3408U 1.8GHz 8-core 1P 16GB-R 8SFF 500W PS Server. Processor family: Intel Xeon Bronze, Processor frequency: 1.8 GHz, Processor model: 3408U. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 16 GB. Total storage capacity: 0 GB, HDD interface: SATA. Ethernet LAN. Power supply: 500 W, Redundant power supply (RPS) support. Chassis type: Rack (1U)
