- E3SUPS10KHB, Doppelwandler (Online), 10 kVA, 10000 W, Reiner Sinus, 304 V, 415 V
2 Images
Product description
High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 10 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime. For battery runtime details, see the runtime charts published under the Documents tab.
Includes: Dust filter, Installation guide.
Includes: Dust filter, Installation guide.
Technical specifications
Leistungen
| ECO mode | Y |
Weight & dimensions
| Weight | 112,000 g |
Power
| Maximum current | 18 A |
Verpackungsdaten
| Quick installation guide | Y |
| Package weight | 145,000 g |
| Package depth | 1,014 mm |
| Package width | 563 mm |
| Package height | 1,640 mm |
Sonstige Funktionen
| International Protection (IP) code | IP20 |
| Input frequency | 45/65 |
| Output power | 10,000 W |
| Noise level | 60 dB |
| Nominal input voltage | 400 |
| Nominal output voltage | 400 |
Operational conditions
| Operating relative humidity (H-H) | 0 - 95 |
| Storage temperature (T-T) | -15 - 40 |
| Operating temperature (T-T) | 0 - 40 |
| Operating altitude | 0 - 999.9 |
| Storage relative humidity (H-H) | 0 - 95 |
| Non-operating altitude | 0 - 15000 |
Battery
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 240 V |
| Waveform | Pure sine |
Ergonomics
| LED indicators | Y |
Features
| Height | 1,400 mm |
| Width | 380 mm |
| Depth | 928 mm |
| Number of output phases | 3 |
| UPS topology | Double-conversion (Online) |
| Number of input phases | 3 |
| Input power factor | 0.99 |
| Efficiency | 94.8 % |
| Output power capacity | 10 kVA |
| Output voltage Total Harmonic Distortion (THD) | 3 % |
| Input operation voltage (max) | 415 V |
| Input operation voltage (min) | 304 V |
| Output operation voltage (min) | 380 V |
| Output operation voltage (max) | 477 V |
| Output frequency | 50/60 |
Mouse
| Form factor | Tower |
| Certification | CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE REACH |
Ports & interfaces
| Parallel ports quantity | 1 |
Design
| Product colour | White |
Downloads
521386_document_EN_001
PDF Download
Reviews
ID: 521386
APC ID: E3SUPS10KHB
E3SUPS10KHB, Doppelwandler (Online), 10 kVA, 10000 W, Reiner Sinus, 304 V, 415 V
Detailed product title
Detailed product title
APC E3SUPS10KHB. UPS topology: Double-conversion (Online), Output power capacity: 10 kVA, Output power: 10000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 240 V. Form factor: Tower, Product colour: White, International Protection (IP) code: IP20. Certification: CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE REACH. Width: 380 mm, Depth: 928 mm, Height: 1400 mm
