ID: 318244 Iiyama ID: T2754MSC-B1AG

ProLite T2754MSC-B1AG 68,6cm (27") 1920x1080 Pixel 1000:1 300cd/m² 4ms

Detailed product title

Iiyama ProLite T2754MSC-B1AG 68,6cm (27") 1920x1080 Pixel 1000:1 300cd/m² 4ms

Response time 4

Display resolution 1920 x 1080

Contrast ratio (typical) 1000:1

Display brightness (typical) 300

Display diagonal 27

Product colour Black

Height adjustment Yes

Built-in speaker(s) Yes

immediately

Added to cart

immediately

Product description

Touch technology - capacitive
This technology uses a sensor network of microfine wires that are integrated into the glass surface. When the screen is touched, electrical signals are changed and the touch position can be calculated and passed on to the controller. The glass surface of this technology is extremely durable, the touch functionality remains unaffected even if the glass is scratched. It offers perfect image reproduction and can be operated with fingers (even with latex gloves) or magnetic pens.
IPS
IPS displays are particularly known for wide viewing angles and natural, highly accurate colors. They are particularly suitable for color-critical applications.
AG coating
The AG coating is used on professional displays to reduce reflections from external light sources that can affect colors, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt particles.
VESA
A standard that allows you to easily attach a wall or table mount.

Technical specifications

Logistics data

Harmonized System (HS) code	85285210
Products per pallet	20

Leistungen

Flicker-free technology	Yes
Low Blue Light technology	Yes
Mean time between failures (MTBF)	50,000

Design

Product colour	Black
Front bezel colour	Black

Power

Energy efficiency class (SDR)	F
Energy efficiency class (HDR)	Not available
Power consumption (typical)	27
Power consumption (off)	0.3
Power consumption (standby)	0.5
AC input voltage	100 - 240
AC input frequency	50 - 60
AC adapter output voltage	19
Energy consumption (SDR) per 1000 hours	26

Lieferumfang

Cables included

AC,USB,HDMI

Technische Details

User controls	Picture adjust (brightness, contrast, Eco, i-Style Color, adv. contrast), Geometry (pixel clock, phase, horizontal position, vertical position, aspect), Color settings (gamma, color temp), OSD (OSD horizontal position, OSD vertical position, OSD time, language, auto power off, touch wake up), Extra (reset, signal select, audio input, opening logo, LED, Overdrive, Information, volume, auto adjust)
Pallet net length	698
Pallet net height	2,058
Pallet net width	1,246

Verpackungsdaten

Quick start guide	Yes
Package weight	8,400
Package depth	204
Package width	688
Package height	477

Sonstige Funktionen

Power supply type	External
Touch method	stylus, finger, glove (latex)
Digital horizontal frequency	30 - 83
Display diagonal (metric)	68.6

Sustainability

Sustainability certificates	ErP
Compliance certificates	CE,EAC,REACH,RoHS,UKCA,WEEE

Operational conditions

Operating relative humidity (H-H)	10 - 85
Storage temperature (T-T)	-20 - 60
Operating temperature (T-T)	5 - 35
Storage relative humidity (H-H)	5 - 90

Ergonomics

Cable lock slot type	Kensington
Cable lock slot	Yes
VESA mounting	Yes
On Screen Display (OSD) languages	DEU,ENG,ESP,FRE,ITA,JPN,DUT,POL,POR,RUS
Height adjustment	Yes
Number of OSD languages	10
On Screen Display (OSD)	Yes
Tilt angle range	5 - 90
Panel mounting interface	100 x 100
Height adjustment	297.5

Features

Compatible operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Colour depth	8

Multimedia

Number of speakers	2
Built-in camera	No
Built-in speaker(s)	Yes
Built-in microphone	No
RMS rated power	4

Display

Display technology	LED
Touchscreen type	Multi-user
Panel type	IPS
Screen shape	Flat screen
Display number of colours	16.7 million colours
Anti-glare screen	Yes
Touchscreen	Yes
Number of simultaneous touchpoints	10
Pixel pitch	0.311 x 0.311
Viewable size, horizontal	597.89
Viewable size, vertical	336.31
Display viewable area (HxV)	597.89 x 336.31
Response time	4
Display diagonal	27
Display resolution	1920 x 1080
Viewing angle, horizontal	178
Viewing angle, vertical	178
Maximum refresh rate	60
Display brightness (typical)	300
Active display area (W x H)	597.89 x 336.31

Graphics

NVIDIA G-SYNC	No
AMD FreeSync	No

Video

HD type

Full HD

Projector

Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
Contrast ratio (dynamic)	80000000:1
Horizontal scan range	30 - 83

Ports & interfaces

VGA (D-Sub) ports quantity	1
HDMI ports quantity	1
HDCP	Yes
HDMI	Yes
Audio input	1
USB ports quantity	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
USB Type-A downstream ports quantity	1
Built-in USB hub	Yes
