Product colour | Grey |
Wall mountable | Y |
Console port | RJ-45 |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Web-based management | Y |
MAC address table | 16,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Auto MDI/MDI-X | Y |
Multicast support | Y |
VLAN support | Y |
Number of VLANs | 4,094 |
Jumbo frames | 9,600 |
Broadcast storm control | Y |
Spanning tree protocol | Y |
10G support | N |
Switching protocols | RSTP, STP, LLDP, CDP |
Management protocols | SNMP |
Switch type | Managed |
Switch layer | L2 |
Access Control List (ACL) | Y |
IGMP snooping | Y |
DHCP features | DHCP server,DHCP snooping,DHCP client |
Root protection | Y |
BPDU filtering/protection | Y |
Energy consumption | 9 W |
AC input voltage | 100 - 240 |
AC input frequency | 47/63 |
DC input voltage | 56 |
Power consumption (max) | 16 W |
Power over Ethernet (PoE) | Y |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | 0 - 40 |
Networking standards | IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1p, |
Rack mounting | N |
Input current | 2.7 |
Switching capacity | 20 Gbit/s |
Weight | 1,550 g |
Height | 44 mm |
Width | 227 mm |
Depth | 230 mm |
Harmonized System (HS) code | 85176990 |
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 8
Power over Ethernet (PoE) Y
Switch type Managed
Product colour | Grey |
Wall mountable | Y |
Console port | RJ-45 |
SFP module slots quantity | 2 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power connector | DC-in jack |
Basic switching RJ-45 Ethernet ports quantity | 8 |
Web-based management | Y |
MAC address table | 16,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Auto MDI/MDI-X | Y |
Multicast support | Y |
VLAN support | Y |
Number of VLANs | 4,094 |
Jumbo frames | 9,600 |
Broadcast storm control | Y |
Spanning tree protocol | Y |
10G support | N |
Switching protocols | RSTP, STP, LLDP, CDP |
Management protocols | SNMP |
Switch type | Managed |
Switch layer | L2 |
Access Control List (ACL) | Y |
IGMP snooping | Y |
DHCP features | DHCP server,DHCP snooping,DHCP client |
Root protection | Y |
BPDU filtering/protection | Y |
Energy consumption | 9 W |
AC input voltage | 100 - 240 |
AC input frequency | 47/63 |
DC input voltage | 56 |
Power consumption (max) | 16 W |
Power over Ethernet (PoE) | Y |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | 0 - 40 |
Networking standards | IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1p, |
Rack mounting | N |
Input current | 2.7 |
Switching capacity | 20 Gbit/s |
Weight | 1,550 g |
Height | 44 mm |
Width | 227 mm |
Depth | 230 mm |
Harmonized System (HS) code | 85176990 |
