- ZD200 Series ZD230 Etikettendrucker Ther




























Just the Features You Need
This 4-inch printer produces labels quickly, up to 6” per second, to keep your workflows moving. Increased memory allows you to store more fonts and graphics. A single LED indicator and single button for feed/pause make it easy to operate and identify printer status. Choose from direct thermal or thermal transfer models, and add an optional factory-installed peeler or cutter. The ZD230 features a core set of Print DNA software applications, powered by Link-OS Basic, to deliver a cost-effective and dependable print experience. It is ideal for use in transportation and logistics, light manufacturing, retail and healthcare applications to print a variety of tickets, tags, passes, labels and receipts.
Backed by Zebra’s Worldwide Service and Support
Access support quickly anywhere around the globe through Zebra’s trusted network of more than 10,000 partners. Avoid costly repairs and downtime with an affordable service plan that’s tailored to the coverage you need for your desktop printer. Zebra’s OneCare SV provides the right level of service at the right price. It gives you two years of coverage for normal wear and tear, double the standard warranty coverage, priority turnaround times at the depot and more—all for a tiny fraction of the cost of a single repair.
Consistently Exceptional Zebra Certified Supplies
Printing supplies can impact everything from printhead lifespan to operational efficiency. That’s why we design, produce and rigorously pretest our own line of thermal printing supplies to ensure consistent, optimised performance in your Zebra printer—and peace of mind for you. For industry-leading quality, service and thermal printing expertise, choose Zebra Certified Supplies.
The ZD230 gives you more. The quality and reliability you expect from Zebra, along with the extra features you need. And, it helps you conserve costs now, and for years to come. Gain your competitive edge with Zebra.
Get Printing Quickly
The ZD230 is simple to install and begin printing – right out of the box. Easily replace legacy printers using ZPL, EPL or non- Zebra command languages. USB, Ethernet, Wi-Fi and Bluetooth® connectivity options enable universal interoperability. The ZD230 can accommodate a 300 M ribbon roll to lengthen the time between media changes. And, Zebra’s OpenACCESS™ clamshell design expedites media replacement. It’s also ENERGY STAR® qualified to reduce your operational expenses.
Product colour | Black |
Built-in display | N |
Number of fonts | 23 |
AC input voltage | 100 - 240 |
AC input frequency | 50 - 60 |
Cables included | AC |
Quantity per pack | 1 ST |
Media thickness | 0.08 - 0.1905 |
Supported paper width | 25.4 - 112 |
Maximum label width | 112 mm |
Maximum label length | 0.991 m |
Display | N |
Colour | N |
USB port | Y |
Internal memory | 128 MB |
Flash memory | 256 MB |
Print speed | 152 mm/s |
Operating relative humidity (H-H) | 10 - 90 |
Storage temperature (T-T) | -40 - 60 |
Operating temperature (T-T) | 4.4 - 41 |
Storage relative humidity (H-H) | 5 - 95 |
Built-in barcodes | 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 128 (A/B/C),Code 39,Code 49,Code 93,Data Matrix,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E |
Page description languages | EZPL,XML,ZPL II |
Maximum resolution | 203 x 203 |
Maximum printing width | 104 mm |
Maximum roll diameter | 127 mm |
Weight | 1,100 g |
Height | 191 mm |
Width | 197 mm |
Depth | 267 mm |
Ribbon length | 300 m |
Core diameter | 12.7 mm |
Ribbon width | 109.2 mm |
Print technology | Thermal transfer |
Certification | IEC 60950-1, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus, CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM |
Connectivity technology | Wired |
USB 2.0 ports quantity | 1 |
Ethernet LAN | N |
Wi-Fi | N |
Bluetooth | N |







Connectivity technology Wired
Maximum resolution 203 x 203
Print technology Thermal transfer
Maximum printing width 104 mm
Just the Features You Need
This 4-inch printer produces labels quickly, up to 6” per second, to keep your workflows moving. Increased memory allows you to store more fonts and graphics. A single LED indicator and single button for feed/pause make it easy to operate and identify printer status. Choose from direct thermal or thermal transfer models, and add an optional factory-installed peeler or cutter. The ZD230 features a core set of Print DNA software applications, powered by Link-OS Basic, to deliver a cost-effective and dependable print experience. It is ideal for use in transportation and logistics, light manufacturing, retail and healthcare applications to print a variety of tickets, tags, passes, labels and receipts.
Backed by Zebra’s Worldwide Service and Support
Access support quickly anywhere around the globe through Zebra’s trusted network of more than 10,000 partners. Avoid costly repairs and downtime with an affordable service plan that’s tailored to the coverage you need for your desktop printer. Zebra’s OneCare SV provides the right level of service at the right price. It gives you two years of coverage for normal wear and tear, double the standard warranty coverage, priority turnaround times at the depot and more—all for a tiny fraction of the cost of a single repair.
Consistently Exceptional Zebra Certified Supplies
Printing supplies can impact everything from printhead lifespan to operational efficiency. That’s why we design, produce and rigorously pretest our own line of thermal printing supplies to ensure consistent, optimised performance in your Zebra printer—and peace of mind for you. For industry-leading quality, service and thermal printing expertise, choose Zebra Certified Supplies.
The ZD230 gives you more. The quality and reliability you expect from Zebra, along with the extra features you need. And, it helps you conserve costs now, and for years to come. Gain your competitive edge with Zebra.
Get Printing Quickly
The ZD230 is simple to install and begin printing – right out of the box. Easily replace legacy printers using ZPL, EPL or non- Zebra command languages. USB, Ethernet, Wi-Fi and Bluetooth® connectivity options enable universal interoperability. The ZD230 can accommodate a 300 M ribbon roll to lengthen the time between media changes. And, Zebra’s OpenACCESS™ clamshell design expedites media replacement. It’s also ENERGY STAR® qualified to reduce your operational expenses.
Product colour | Black |
Built-in display | N |
Number of fonts | 23 |
AC input voltage | 100 - 240 |
AC input frequency | 50 - 60 |
Cables included | AC |
Quantity per pack | 1 ST |
Media thickness | 0.08 - 0.1905 |
Supported paper width | 25.4 - 112 |
Maximum label width | 112 mm |
Maximum label length | 0.991 m |
Display | N |
Colour | N |
USB port | Y |
Internal memory | 128 MB |
Flash memory | 256 MB |
Print speed | 152 mm/s |
Operating relative humidity (H-H) | 10 - 90 |
Storage temperature (T-T) | -40 - 60 |
Operating temperature (T-T) | 4.4 - 41 |
Storage relative humidity (H-H) | 5 - 95 |
Built-in barcodes | 1D,2D,AZTECCODE,CODABAR (NW-7),Code 11,Code 128 (A/B/C),Code 39,Code 49,Code 93,Data Matrix,EAN13,EAN8,Industrial 2/5,Interleaved 2/5,MaxiCode,PDF417,POSTNET,QR Code,UPC-A,UPC-E |
Page description languages | EZPL,XML,ZPL II |
Maximum resolution | 203 x 203 |
Maximum printing width | 104 mm |
Maximum roll diameter | 127 mm |
Weight | 1,100 g |
Height | 191 mm |
Width | 197 mm |
Depth | 267 mm |
Ribbon length | 300 m |
Core diameter | 12.7 mm |
Ribbon width | 109.2 mm |
Print technology | Thermal transfer |
Certification | IEC 60950-1, EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus, CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM |
Connectivity technology | Wired |
USB 2.0 ports quantity | 1 |
Ethernet LAN | N |
Wi-Fi | N |
Bluetooth | N |
