ID: 126047 APC ID: SRT5KRMXLI

Smart-UPS SRT 5000VA RM 230V schwarz

Detailed product title

APC Smart-UPS SRT, 5000VA, RM 3HE, 230V, schwarz, Bleisäure, Wartungsfrei, versiegelt, auslaufsicher, USB, RJ-45, EPO, 2 Jahre Bring -In Herstellergarantie

Product colour Black

immediately

Added to cart

immediately

Product description

APC Smart UPS SRT

Die APC Smart UPS SRT ist ein optimales USV-System für die IT-Umgebung. Sie besitzt eine innovative D oppelwandler Technologie mit höchster Klassifizierung nach VFI-SS-111. Sie kann wahlweise als Stand-Alone Towergerät oder in ein 19 -Rack integriert werden. Der Platzbedarf im Rack beträgt in der RMXLI-Variante 3 HE. Durch das Hinzufügen von externen Batteriepac s ist die Autonomiezeit erweiterbar.

Technical specifications

Logistics data

Products per pallet

6 ST

Design

Product colour	Black
Temperature sensor	Y
Rack capacity	3U

Power

Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	1.5 std
Surge protection	Y

Lieferumfang

Rack mount kit

Verpackungsdaten

Warranty card	Y
Quick installation guide	Y
Package weight	66,860 g
Package depth	960 mm
Package width	610 mm
Package height	330 mm

Sonstige Funktionen

USB port	Y
Input frequency	40 - 70
Output power	4,500 W
Noise level	55 dB

Sustainability

Sustainability certificates	ENERGY STAR
Compliance certificates	RoHS

Operational conditions

Operating relative humidity (H-H)	0 - 95
Storage temperature (T-T)	-15 - 45
Operating temperature (T-T)	0 - 40
Operating altitude	0 - 3000
Storage relative humidity (H-H)	0 - 95
Non-operating altitude	0 - 15000

Battery

Hot-swap battery	Y
Waveform	Sine
Replacement battery cartridge	APCRBC140
Cold start	Y
Automatic battery test	Y
Typical backup time at half load	11.8 min
Battery capacity	845 Vah
Typical backup time at full load	4 min
Battery life (max)	5

Features

Audible alarm(s)	Y
Output frequency regulation	50/60
Crest factor	3:1
UPS topology	Double-conversion (Online)
Auto-restart	Y
Emergency Power Off (EPO)	Y
Efficiency	94.1 %
Surge energy rating	480 J
Output power capacity	5 kVA
Output voltage Total Harmonic Distortion (THD)	3 %
Input operation voltage (max)	275 V
Input operation voltage (min)	100 V
Output operation voltage (min)	220 V
Output operation voltage (max)	240 V

Mouse

Form factor	Rackmount
Certification	REACH, CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE

Ports & interfaces

Serial interface type	RJ-45
Power plug	Hardwire
AC outlet types	C13 coupler,C19 coupler
Number of output IEC jumpers	2
Serial interface	Y
SmartSlot	Y
AC outlets quantity	10 AC out
