Cisco Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
The Meraki MS is managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files or even direct physical access to the switch.
Meraki’s centralized management gives administrators deep visibility into the network and how it’s used. See which switches are near capacity across hundreds of sites. Find all configuration changes made by a certain person with instant search.
INDUSTRY LEADING CLOUD MANAGEMENT
Cloud management has a number of benefits that make it easier to build networks large and small:
- True zero-touch device provisioning.
- Virtual stacking: manage up to thousands of ports from a single pane of glass.
- Application layer visibility with automatic operating system, client, and hostname fingerprinting.
- Powerful Live Tools such as packet capture and cable test to isolate and troubleshoot network issues.
- Alerts upon power loss, downtime, or configuration changes.
- Role-based administration and automatic, scheduled firmware upgrades over the web.
- Regular feature updates and enhancements delivered on demand from the Meraki cloud.
Product colour | Aluminium |
Form factor | 1U |
Stackable | Y |
Console port | RJ-45 |
SFP module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Security algorithms | SNMP |
Web-based management | Y |
MAC address table | 16,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Link aggregation | Y |
Multicast support | Y |
VLAN support | Y |
Static route | Y |
Number of VLANs | 4,094 |
Jumbo frames | 9,578 |
Port mirroring | Y |
Forwarding rate | 41.67 Mpps |
Virtual LAN features | Voice VLAN |
Broadcast storm control | Y |
Spanning tree protocol | Y |
10G support | N |
Certification | CSA-US, FCC, IC, CE, RCM, RoHS |
Mean time between failures (MTBF) | 391,648 std |
Physical stacking (units) | 8 |
Switching protocols | LLDP, CDP, RSTP, STP |
Firmware upgradeable | Y |
Switch type | Managed |
Password protection | Y |
Access Control List (ACL) | Y |
System event log | Y |
IGMP snooping | Y |
Authentication type | RADIUS |
Authentication | MAC-based authentication |
DHCP features | DHCP snooping,DHCP relay,DHCP client |
BPDU filtering/protection | Y |
Energy consumption | 448 W |
AC input voltage | 100 - 240 |
Screws included | Y |
Redundant power supply (RPS) support | Y |
AC input frequency | 47/63 |
Power over Ethernet (PoE) | Y |
Power over Ethernet plus (PoE+) ports quantity | 24 |
Total Power over Ethernet (PoE) budget | 370 W |
Power over Ethernet (PoE) power per port | 30 W |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | 0 - 40 |
Networking standards | IEEE 802.11w,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab, |
Rack mounting | Y |
Switching capacity | 128 Gbit/s |
Weight | 3,710 g |
Height | 43.8 mm |
Width | 484.6 mm |
Depth | 250 mm |
Harmonized System (HS) code | 85176990 |
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity 24
Power over Ethernet (PoE) Y
Switch type Managed
Cisco Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
The Meraki MS is managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files or even direct physical access to the switch.
Meraki’s centralized management gives administrators deep visibility into the network and how it’s used. See which switches are near capacity across hundreds of sites. Find all configuration changes made by a certain person with instant search.
INDUSTRY LEADING CLOUD MANAGEMENT
Cloud management has a number of benefits that make it easier to build networks large and small:
- True zero-touch device provisioning.
- Virtual stacking: manage up to thousands of ports from a single pane of glass.
- Application layer visibility with automatic operating system, client, and hostname fingerprinting.
- Powerful Live Tools such as packet capture and cable test to isolate and troubleshoot network issues.
- Alerts upon power loss, downtime, or configuration changes.
- Role-based administration and automatic, scheduled firmware upgrades over the web.
- Regular feature updates and enhancements delivered on demand from the Meraki cloud.
Product colour | Aluminium |
Form factor | 1U |
Stackable | Y |
Console port | RJ-45 |
SFP module slots quantity | 4 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Security algorithms | SNMP |
Web-based management | Y |
MAC address table | 16,000 entrie |
Quality of Service (QoS) support | Y |
Jumbo frames support | Y |
Link aggregation | Y |
Multicast support | Y |
VLAN support | Y |
Static route | Y |
Number of VLANs | 4,094 |
Jumbo frames | 9,578 |
Port mirroring | Y |
Forwarding rate | 41.67 Mpps |
Virtual LAN features | Voice VLAN |
Broadcast storm control | Y |
Spanning tree protocol | Y |
10G support | N |
Certification | CSA-US, FCC, IC, CE, RCM, RoHS |
Mean time between failures (MTBF) | 391,648 std |
Physical stacking (units) | 8 |
Switching protocols | LLDP, CDP, RSTP, STP |
Firmware upgradeable | Y |
Switch type | Managed |
Password protection | Y |
Access Control List (ACL) | Y |
System event log | Y |
IGMP snooping | Y |
Authentication type | RADIUS |
Authentication | MAC-based authentication |
DHCP features | DHCP snooping,DHCP relay,DHCP client |
BPDU filtering/protection | Y |
Energy consumption | 448 W |
AC input voltage | 100 - 240 |
Screws included | Y |
Redundant power supply (RPS) support | Y |
AC input frequency | 47/63 |
Power over Ethernet (PoE) | Y |
Power over Ethernet plus (PoE+) ports quantity | 24 |
Total Power over Ethernet (PoE) budget | 370 W |
Power over Ethernet (PoE) power per port | 30 W |
Operating relative humidity (H-H) | 5 - 95 |
Operating temperature (T-T) | 0 - 40 |
Networking standards | IEEE 802.11w,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab, |
Rack mounting | Y |
Switching capacity | 128 Gbit/s |
Weight | 3,710 g |
Height | 43.8 mm |
Width | 484.6 mm |
Depth | 250 mm |
Harmonized System (HS) code | 85176990 |
